Use of CO₂ in video assisted thoracic surgery and single-lumen endotracheal tube—a new less invasive approach

Introduction

Carbon dioxide (CO₂) has been extensively used to allow laparoscopic procedures, due to its advantages in obtaining a fairly innocuous pneumoperitoneum to allow visceral dissection. As advantages in its use, absence of a deleterious effect for the tissues it contacts with, and quick body resorption for small amounts have been cited.

Modern thoracic surgery nowadays relies on single lung ventilation, achieved through double lumen endotracheal tube or a bronchial blocker. The disadvantages of these two techniques are widely known, and include difficulty in accurately placing the double lumen tube, intra-operatory dislodgment of the tube, frequent need for fiber-optic bronchoscope support and need for more prolonged and deep anesthesia. Across many centers, experience with double lumen intubation is also not frequent.

Video assisted thoracic surgery (VATS) nowadays allows most thoracic procedures to be undertaken. The use of video has revolutionized all surgery, and thoracic surgery has benefited greatly from this technique.

Nevertheless, up until recently, VATS has made the use of selective lung ventilation mandatory, and surgeries which could be relatively easily accomplished with an open thoracotomy using a single tube are nearly impossible by VATS with a single tube.

In the last three years, our group has been using CO₂ coupled with single tube tracheal intubation as a means to create a space in the pleural cavity in which instruments can be mobilized and operations undertaken. After surgery, any residual gas left in the pleural cavity is more easily absorbed by the pleural cavity, as has been known for many years since the development of laparoscopic surgery. This represents an enormous advantage in favor of using this technique, since frequently a chest drain can be avoided and hospital stay shortened.

We have been expanding the uses of this technique and believe it offers important advantages in several types of thoracic surgery, especially pneumothorax surgery.

Technique

The patient is placed in supine position and after general anesthesia single lumen tracheal intubation is obtained. An arterial line (usually left radial artery) is placed. Depending on the surgery which will be undertaken, we use from one to three valved trocars. An incision is made in the appropriate place and the first trocar in introduced with the patient temporarily disconnected from the ventilator, to avoid lung laceration. We then start the CO₂ insufflation at 3 L/min, with a pressure of 5 to 6 mmHg. If for some reason lung adhesions are present and no partial collapse is obtained, the CO₂ insufflator may alarm high pressure, which leads us to reconsider the surgical approach.

Most of the times, a satisfactory partial lung collapse is obtained and the remaining trocars are introduced. Constant surveillance of the heart rhythm and invasive arterial pressure is undertaken by the anesthetist and the surgeon to detect early mediastinal shift. The usual signs of mediastinal shift in this situation are hypotension and bradycardia. Should any of these or other electrical or hemodinamical disturbances occur, the intra pleural pressure is allowed to normalize instantly through one of the valved trocars, and the CO₂ pressure in the insufflator is diminished.

The surgery is performed in the usual way, and in the end, depending on the surgery, simple aspiration of the pleural space is performed with a nasogastric probe through the trocar, or chest drains are placed. The rest of the procedure is similar to the usual thoracoscopic surgery, and anesthesia is easily terminated, due to less profound sedation and less invasive ventilation performed.

General advantages

• Faster anesthesia;
• Single lumen tube ventilation (less invasive);
• Easier anesthesia;
• No dependance on existence of fiber-optic bronchoscopy;
• No dependence on anesthetic experience with double-lumen intubation;
• Less probability of lasting pneumothorax, quicker absorption of pneumothorax, allowing avoidance of chest drains in some situations;
• Quicker recovery and earlier hospital discharge.

General disadvantage

Need of arterial invasive monitoring due to risk of mediastinal shift in selected cases.

Special considerations according to the type of surgery performed:

Sympathectomy

• Allows avoidance of chest tube drainage (the CO₂ is aspirated at the end of the surgery);
• Allows earlier hospital discharge.

In sympathectomy, we do a 5 mm incision in the 3rd intercostal space and place a nylon stitch on that same incision for easy closure after trocar removal. We use a 5 mm valved trocar and initiate CO₂ insufflation. We insert the 5 mm optic and then we do a second 5 mm incision on the 5th intercostal space, place the another stitch and use a second valved trocar. After sympathetic nerve clipping, we place an apical nasogastric suction tube through the 5th intercostal space incision, check that the CO₂ is diminishing, ask the anesthetist to manually inflate the lung and remove both trocars, pulling the nasogastric suction probe. Residual CO₂ is easily and quickly absorbed by the pleura (Figure 1).

Figure 1 Sympathectomy with clipping using CO₂—perfect visualization is obtained using single lumen tracheal intubation and CO₂ (1). Available online: http://www.asvide.com/articles/1359

Pneumothorax/emphysema surgery

• Greatly improves visualization of the bullae;
• Diminishes probability of leaving unresected bullae;
• Greatly facilitates localization of fistula.

Pneumothorax surgery is greatly facilitated with the use of CO₂ insufflation. Besides all the advantages with the anesthetic management, the presence of some pressure on the diseased lung causes the bullae to be expanded, while the CO₂ still allows for a generous space which allows the surgery to be undertaken. In the case of pleural fistulae, the maintenance of pressure on the airways, and the diseased lung, while maintaining a pleural space, allows very easy detection of the disrupted pleura with the use of irrigation of the pleural surface, something not easily done with double lumen ventilation. Due to the nature of the underlying disease, and the need for pleurectomy and the associated risk of bleeding, we always leave an apical and a basal drain (Figure 2).

Figure 2 Pleural bleb resection in pneumothorax—use of CO₂ allows for blebs expansion and easier visualization (2). Available online: http://www.asvide.com/articles/1361

Pericardial and mediastinal cysts, mediastinal node biopsy

• Avoidance of sternotomy and chest drain.

In simple pericardial and mediastinal cysts and nodes, CO₂ allows for easy resection of the lesions. Should hemostasis prove to be perfect at the end of the resection, a simple suction of the pleural cavity, as described earlier for sympathectomy, may be performed, and a chest drain avoided. Avoidance of sternotomy and chest drains allows for drastically diminished hospital stay.

Pericardial effusion/tamponade—creation of pleuropericardial window

• Allows quicker and less profound anestesia in unstable patients.

In selected cases of pericardial effusion and tamponade, if a pleuropericardial window is being considered as an option in unstable patients, CO₂ inflation is a safe choice, allowing quicker and safer anesthesia. In unstable cases, the CO₂ insufflation pressure used is lower (3 mmHg). These patients are operated with a pillow under the right side of the thorax to slightly rotate the thorax to the contralateral side. Chest drains, which may be intrapericardial, are always placed.

Nuss surgery for pectus excavatum

• Allows safe passage of Nuss dissector and bar;
• Does not preclude use of chest drain due to contra-lateral pneumothorax.

While performing Nuss surgery for correction of pectus excavatum, CO₂ insufflation is very helpful.

An arterial line placement is standard procedure in our group when the Nuss procedure is done.

The creation of a pneumothorax allows for safe passage of the Nuss dissector and the bar, and is still performed by most surgeons performing Nuss procedures. CO₂ inflation allows avoidance of double lumen intubation, which is very important in patients which are frequently young and have small diameter airways.

Due to the fact that CO₂ usually permeates through the pathway created by the dissector to the contralateral hemithorax, we always leave a single chest drain on the right side of the patient. We found the gas on the left hemithorax is not easily aspirated from the right side during the surgery and takes some time to permeate to the right side again. The chest drain is normally left for three days to allow complete CO₂ absorption and aspiration, (the usual hospital stay due to pain control Nuss surgery normally necessitates), so CO₂ inflation does not increase hospital stay in this setting.

Atrial fibrillation and left atrial appendage occlusion

Thoracoscopic ablation of atrial fibrillation is always done with arterial line placement.

CO₂ inflation assures absence of lung inflation during very delicate and risky cardiac manipulation. Sudden lung inflation, which may occur during double lumen intubation due to dislodgment of the endotracheal tube with catastrophic consequences, is avoided by use of CO₂ inflation. Bilateral chest drains are always placed in this procedure.

Acknowledgements

None.

Footnote

Conflicts of Interest: The authors have no conflicts of interest to declare.

References

1. Gallego-Poveda J, Guerra NC, Carvalheiro C, et al. Sympathectomy with clipping using CO—perfect visualization is obtained using single lumen tracheal intubation and CO. Asvide 2017;4:062. Available online: http://www.asvide.com/articles/1359
2. Gallego-Poveda J, Guerra NC, Carvalheiro C, et al. Pleural bleb resection in pneumothorax—use of CO allows for blebs expansion and easier visualization. Asvide 2017;4:063. Available online: http://www.asvide.com/articles/1361
