Development of pulmonary Langerhans cell histiocytosis in a patient with established adenocarcinoma of the lung
Case Report

Development of pulmonary Langerhans cell histiocytosis in a patient with established adenocarcinoma of the lung

Or Kalchiem-Dekel1, Adina Paulk2, Seth J. Kligerman3, Allen P. Burke2, Nirav G. Shah1, Renee K. Dixon1

1Division of Pulmonary and Critical Care Medicine, 2Department of Pathology, 3Department of Diagnostic Radiology and Nuclear Medicine, University of Maryland School of Medicine, Baltimore, MD, USA

Correspondence to: Or Kalchiem-Dekel, MD. Division of Pulmonary and Critical Care Medicine, University of Maryland School of Medicine, 110 S. Paca Street, Baltimore, MD 21201, USA. Email: orkalchiemdekel@umm.edu.

Abstract: Newly-appearing lung nodules on surveillance imaging in patients with pre-existing lung cancer can present a diagnostic dilemma when attempting to differentiate between metastatic disease, infection, and other inflammatory conditions. Here we report a case of an EGFR−/ALK−/BRAF+ metastatic adenocarcinoma patient who underwent lung biopsy for evaluation of upper-lobe predominant lung nodules revealed to represent pulmonary Langerhans cell histiocytosis (PLCH). The patient was a heavy smoker and admitted to increase her smoking habit after initially learning about her diagnosis with lung cancer. Interestingly, despite the association of both lung adenocarcinoma and PLCH with the BRAFV600E mutation in smokers, pyrosequencing of the patient’s PLCH lesions was negative for this mutation. Co-occurrence of PLCH with lung cancer is extremely rare. While most reported cases of PLCH tend to precede the occurrence of lung cancer, a minority of cases appear after a diagnosis of lung cancer has already been established and are thought to represent a local immunologic reaction to the tumor. It is therefore postulated that the appearance of PLCH lesions in this patient’s lungs is a result of her increase in cigarette smoking, possibly augmented by co-existence of adenocarcinoma.

Keywords: Adenocarcinoma of lung; BRAF mutation; pulmonary Langerhans cell histiocytosis (PLCH)


Submitted Jun 30, 2017. Accepted for publication Nov 01, 2017.

doi: 10.21037/jtd.2017.11.12


Introduction

Surveillance imaging for follow-up of patients with advanced stage non-small cell lung cancer during remission is endorsed by prominent oncologic societies due to the high rate of recurrence and clear benefits of second-line therapy in patients with an initial response to first-line chemotherapy (1). Cancer patients with new pulmonary findings on surveillance imaging present a diagnostic dilemma and often require tissue acquisition to differentiate between infectious versus neoplastic etiologies, among others, in order to determine the appropriate treatment course. Herein, we describe a case of newly appearing multiple pulmonary nodules representing pulmonary Langerhans cell histiocytosis (PLCH) in a female patient with an established synchronous diagnosis of metastatic adenocarcinoma of the lung. Written informed consent was obtained from the patient for publication of this case report and any accompanying images.


Case presentation

A 56-year-old female patient presented in November 2015 for evaluation of expanding upper lobe-predominant nodular lung opacities, observed on computed tomography (CT) imaging. Approximately one year prior to her presentation, she was diagnosed with multifocal adenocarcinoma of the lung metastatic to mediastinal lymph nodes, left adrenal gland, and pleura. The tumor was negative for epidermal growth factor receptor (EGFR) mutation, anaplastic lymphoma kinase (ALK) translocation, and ROS proto-oncogene 1 translocation, but positive for B-Raf proto-oncogene V600E (BRAFV600E) mutation. The patient was a cigarette smoker with 55-pack year history and she admitted significant increase in her smoking habit from one to two packs per day after learning about her diagnosis with cancer. She completed six cycles of chemotherapy with carboplatin and pemetrexed as well as radiation therapy to the main lesion in the right lung and her condition was considered stable, allowing for a “chemotherapy holiday”. Surveillance CT imaging obtained in May 2015 revealed new ill-defined ground glass lung nodules in a bilateral upper lobe distribution. Since the patient was asymptomatic at that time, a mutual decision was made to pursue watchful waiting. Follow-up imaging obtained in September and November demonstrated an increase in number of the nodules, some of which developed a central lucency. The primary tumor and mediastinal lymph nodes remained stable in appearance (Figure 1). The patient remained in her usual state of health and without new constitutional or respiratory symptoms. A comprehensive review of systems was negative. Vital signs were within normal limits and physical examination was unrevealing. However, at this point the patient requested to pursue work-up by an approach that will maximize the diagnostic yield.

Figure 1 Radiographic evolution of pulmonary Langerhans cell histiocytosis, superimposed on pre-existing adenocarcinoma of the lung. (A) Coronal CT image from May 2015 showing a ground glass nodule in the right upper lobe (arrow), corresponding with the patient’s primary adenocarcinoma. Post-radiation changes noted in the right middle lobe (asterisk); (B) coronary CT image from September 2015 showing new numerous upper lobe-predominant ill-defined ground glass nodules (arrowheads). Post-radiation changes are resolving and the right upper lobe adenocarcinoma nodule is stable; (C,D) coronal and axial CT images from November 2015 demonstrating a dramatic increase in the number of nodules with varying attenuation, which appear to be centered around the airways. Some assume a stellate configuration (D, arrow), while others demonstrate central lucency (D, arrowhead). The dominant right upper lobe ground glass nodule was unchanged.

She was referred for a video-assisted thoracoscopic lung biopsy. Examination of a wedge biopsy of the right upper lobe revealed areas of previously known adenocarcinoma (Figure 2) as well as cystic changes and nodular proliferation of mixed inflammatory cells including numerous eosinophils and histiocytes in a stellate configuration around the airways accompanied by areas of respiratory bronchiolitis and interstitial fibrosis. The histiocytes showed abundant eosinophilic cytoplasm and grooved nuclei, and displayed characteristic reactivity for S100 protein and CD1a antigen (Figure 3), confirming the diagnosis of PLCH. Stains and tissue cultures for microorganisms were negative. Pyrosequencing of a PLCH nodule was negative for the BRAFV600E mutation. Examination of a right middle lobe wedge biopsy revealed additional areas involved with adenocarcinoma, but not with PLCH. The patient was reassured as for the non-malignant nature of the new lesions and educated regarding complete smoking cessation as an essential component of treatment of both her malignancy and PLCH. Unfortunately, further information about the state of her disease or condition is unknown as she has elected to continue follow-up with an alternative healthcare provider.

Figure 2 Metastatic pulmonary adenocarcinoma. (A) Low magnification image demonstrating pleural based nodule (Hematoxylin & Eosin, 40×); (B) high magnification image demonstrating infiltrating tumor nests around pre-existing bronchioles with a fibroelastotic background (Hematoxylin & Eosin, 200×).
Figure 3 Pulmonary Langerhans cell histiocytosis. (A) Low magnification image demonstrating areas of cystic change and inflammation (Hematoxylin & Eosin, 40×); (B) high magnification image showing an infiltrate of Langerhans cells with intermixed eosinophils (Hematoxylin & Eosin, 400×); (C) marked positivity of histiocytes to CD1a antigen (anti-CD1a immunohistochemistry, 100×); (D) marked positivity of histiocytes to S-100 protein (anti-S100 immunohistochemistry 100×).

Discussion

PLCH is a rare interstitial lung disease of unknown pathogenesis affecting primarily young adults and strongly associated with cigarette smoking. Radiologically, the disease classically involves the mid-upper lung zones, supporting an inhalational mechanism of injury. CT findings include ill-defined reticular and nodular bronchiolocentric opacities, which often assume a stellate appearance. Over time, those nodules tend to cavitate and coalesce assuming a cystic appearance and may eventually be replaced by fibrous tissue. Pathologically, the stellate nodules correspond with large clusters of S100 protein- and CD1a antigen-positive histiocytes as well as a mixed infiltrate of eosinophils, lymphocytes, plasma cells, and/or neutrophils (2).

Langerhans cells (LC) can often be demonstrated in lesions of lung neoplasia, most frequently adenocarcinoma, but were shown to be immunophenotypically different and less effective in T-cell activation when compared with LC obtained from PLCH lesions (3). Co-occurrence of PLCH and lung cancer is exceedingly rare. In a natural history series of 314 PLCH patients from Mayo Clinic, only 5 had PLCH and concurrent lung cancer, of which 4 were adenocarcinoma and one was small cell carcinoma (4). Associations between PLCH and bronchogenic, large cell, and squamous cell carcinomas have also been reported (5,6). While in many cases PLCH precedes the appearance of cancer and may represent a risk factor for the development of lung neoplasia, it can also appear after a diagnosis of lung cancer has been established, as seen in our case. Hence, it was proposed that PLCH may represent a local reaction of LC in the lung to the tumor (7).

Although generally regarded as a polyclonal non-neoplastic process, a subset of PLCH patients with monoclonal disease has been described. Among several genetic mutations associated with clonal PLCH, the BRAFV600E activating mutation is the most established (8). The BRAF protein coordinates cellular responses involved in cell cycle regulation and cell proliferation, differentiation, survival, and apoptosis. Hence, activating mutations in the BRAF gene have the potential to contribute to clonal cell expansion (9). Indeed, treatment of advanced PLCH with the BRAF inhibitor, vemurafenib, was reported to have resulted in a favorable outcome (10). Interestingly, the same mutation is also observed in 1–3% of non-small cell lung cancer cases, predominantly adenocarcinoma (11). This association, however, was not observed in our patient, whose adenocarcinoma was positive while her PLCH lesions were negative for BRAFV600E, lending support to the assumption that her PLCH represents a separate smoking-related disease process.

Both BRAFV600E-positive lung adenocarcinoma and PLCH occur almost exclusively in smokers (12,13). Although PLCH pathogenesis is poorly understood, it is hypothesized that constituents of cigarette smoke promote cytokine production, specifically granulocyte-monocyte colony stimulating factor (GM-CSF) and tumor growth factor β (TGF-β), by airway epithelial and other airway associated cells. While GM-CSF can facilitate the activation of LC (14), TGF-β promotes local expansion of LC and contributes to tissue remodeling as seen in PLCH (15). Interestingly, both of these cytokines have also been shown to be produced in large quantities by human adenocarcinoma cell lines (16).

Management of patients with PLCH involves primarily smoking cessation. Immunosuppressive therapy, such as glucocorticoids and cytotoxic agents, are reserved for symptomatic subjects not responding to smoking cessation, although no firm data regarding efficacy exits. Lung transplantation may be considered in advanced cases not responsive to medical measures, although recurrence in the transplanted lung can occur.

To conclude, this rare case illustrates the complexity of our expanding knowledge regarding the genetic foundations and the role of different immunologic pathways in both benign and malignant conditions. The finding that in our patient the PLCH lesions were negative for the BRAFV600E mutation, lends support to the theory maintaining that PLCH may have been a result of intensification of tobacco use, possibly facilitated by cytokines produced by the lung adenocarcinoma. This case underscores the need to emphasize complete smoking cessation in order to prevent, or at least reduce the incidence of, all smoking related lung diseases.


Acknowledgements

None.


Footnote

Conflicts of Interest: The authors have no conflicts of interest to declare.

Informed Consent: Written informed consent was obtained from the patient for publication of this manuscript and any accompanying images.


References

  1. Ettinger DS, Wood DE, Aisner DL, et al. Non-small cell lung cancer, version 5.2017, NCCN clinical practice guidelines in oncology. J Natl Compr Canc Netw 2017;15:504-35. [Crossref] [PubMed]
  2. Kligerman S, Franks TJ, Galvin JR. Clinical-radiologic-pathologic correlation of smoking-related diffuse parenchymal lung disease. Radiol Clin North Am 2016;54:1047-63. [Crossref] [PubMed]
  3. Colasante A, Poletti V, Rosini S, et al. Langerhans cells in Langerhans cell histiocytosis and peripheral adenocarcinomas of the lung. Am Rev Respir Dis 1993;148:752-9. [Crossref] [PubMed]
  4. Howarth DM, Gilchrist GS, Mullan BP, et al. Langerhans cell histiocytosis: diagnosis, natural history, management, and outcome. Cancer 1999;85:2278-90. [Crossref] [PubMed]
  5. Lombard CM, Medeiros LJ, Colby TV. Pulmonary histiocytosis X and carcinoma. Arch Pathol Lab Med 1987;111:339-41. [PubMed]
  6. Sadoun D, Vaylet F, Valeyre D, et al. Bronchogenic carcinoma in patients with pulmonary histiocytosis X. Chest 1992;101:1610-3. [Crossref] [PubMed]
  7. Egeler RM, Neglia JP, Aricò M, et al. The relation of Langerhans cell histiocytosis to acute leukemia, lymphomas, and other solid tumors. The LCH-Malignancy Study Group of the Histiocyte Society. Hematol Oncol Clin North Am 1998;12:369-78. [Crossref] [PubMed]
  8. Yousem SA, Dacic S, Nikiforov YE, et al. Pulmonary Langerhans cell histiocytosis: Profiling of multifocal tumors using next-generation sequencing identifies concordant occurrence of BRAF V600E mutations. Chest 2013;143:1679-84. [Crossref] [PubMed]
  9. Davies H, Bignell GR, Cox C, et al. Mutations of the BRAF gene in human cancer. Nature 2002;417:949-54. [Crossref] [PubMed]
  10. Varadi Z, Banusz R, Csomor J, et al. Effective BRAF inhibitor vemurafenib therapy in a 2-year-old patient with sequentially diagnosed Langerhans cell histiocytosis and Erdheim-Chester disease. Onco Targets Ther 2017;10:521-6. [Crossref] [PubMed]
  11. Li MM, Datto M, Duncavage EJ, et al. Standards and Guidelines for the Interpretation and Reporting of Sequence Variants in Cancer: A Joint Consensus Recommendation of the Association for Molecular Pathology, American Society of Clinical Oncology, and College of American Pathologists. J Mol Diagn 2017;19:4-23. [Crossref] [PubMed]
  12. Roden AC, Hu X, Kip S, et al. BRAF V600E expression in Langerhans cell histiocytosis: clinical and immunohistochemical study on 25 pulmonary and 54 extrapulmonary cases. Am J Surg Pathol 2014;38:548-51. [Crossref] [PubMed]
  13. Paik PK, Arcila ME, Fara M, et al. Clinical characteristics of patients with lung adenocarcinomas harboring BRAF mutations. J Clin Oncol 2011;29:2046-51. [Crossref] [PubMed]
  14. Tazi A, Bonay M, Bergeron A, et al. Role of granulocyte-macrophage colony stimulating factor (GM-CSF) in the pathogenesis of adult pulmonary histiocytosis X. Thorax 1996;51:611-4. [Crossref] [PubMed]
  15. Asakura S, Colby TV, Limper AH. Tissue localization of transforming growth factor-beta1 in pulmonary eosinophilic granuloma. Am J Respir Crit Care Med 1996;154:1525-30. [Crossref] [PubMed]
  16. Fukuyama T, Ichiki Y, Yamada S, et al. Cytokine production of lung cancer cell lines: Correlation between their production and the inflammatory/immunological responses both in vivo and in vitro. Cancer Sci 2007;98:1048-54. [Crossref] [PubMed]
Cite this article as: Kalchiem-Dekel O, Paulk A, Kligerman SJ, Burke AP, Shah NG, Dixon RK. Development of pulmonary Langerhans cell histiocytosis in a patient with established adenocarcinoma of the lung. J Thorac Dis 2017;9(12):E1079-E1083. doi: 10.21037/jtd.2017.11.12
