Trans-inferior-pulmonary-ligament VATS basal segmentectomy: application of single-direction strategy in segmentectomy of left S9+10

Introduction

With the extensive application of low-dose computed tomography (CT) screening in lung cancer diagnosis, the detection of early stage lung cancer has increased remarkably (1). Although full lobe resection is the mainstream treatment of early-stage non-small cell lung cancer (NSCLC), limited resection, such as anatomic segmentectomy, plays an important role in the treatment of patients with both stage IA NSCLC and those unable to tolerate lobectomy because of compromised medical conditions (2-7). The intentional use of anatomic segmentectomy for the treatment of small peripheral lung cancers was first described by Jensik et al. in 1973 (8). Despite the rapid development in video-assisted thoracic surgery (VATS) in the past two decades, the VATS segmentectomy still poses a few technical challenges. For our thoracoscopic segmentectomy practice, we adopted the strategy of single-direction thoracoscopic lobectomy that was designed by Liu et al. (9). Taking the left basal S9+10 segmentectomy as an example, we described the technical characteristics of single-direction segmentectomy through an inferior pulmonary ligament approach (Figure 1).

Figure 1 The video depicts a single-direction VATS left S9+10 segmentectomy. The operation was carried out with the single-direction strategy by approaching the inferior pulmonary ligament. The most superficial segmental vein was transected first, followed by the deep bronchi and deeper segmental artery, and the intersegmental fissure was treated last (10). VATS, video-assisted thoracic surgery. Available online: http://www.asvide.com/article/view/28463

Operative techniques

The surgical procedure was performed under general anesthesia with double-lumen intubation. The patient was placed in a full lateral decubitus position. The thoracoscopic port (1 cm) was made in the seventh intercostal space (ICS) on the midaxillary line. The utility incision (2.5 cm) was made on the anterior axillary line in the fourth ICS, and the assistant incision (2 cm) was made in the ninth ICS behind the posterior axillary line.

After the location of the tumor was confirmed by finger palpation, we marked it with a suture. The tumor can also be located preoperatively by a hook-wire puncture if necessary. The utility incision was protected with a silicone rubber wound protector. An endoscopic ring clamp was inserted to grip the left lower lobe cranially. Then, the dissection was initiated from the inferior pulmonary ligament rather than the interlobar fissure. An electrocautery hook and a suction were introduced in the dissection of the inferior pulmonary ligament and the inferior pulmonary vein. After a careful dissection, the branches of the inferior pulmonary vein to the affected segments were skeletonized. The veins to the lateral and posterior basal segments were identified and sectioned with an endo stapler. The segmental veins were located on the intersegmental plane and collected the venous blood of the adjacent segments and were preserved during operation. Then, the segmental bronchus became visible after the dissection of the segmental veins, and the lymph nodes around the segmental bronchus were carefully removed and sent for frozen-section examination. All the branches of the lower lobe bronchus, especially the superior bronchi, need to be revealed for the identification of the right bronchi of the target segments. After the segmental lymph nodes were confirmed to be negative for cancer, the lateral and posterior basal segmental bronchus was clamped, and the participating lobe was inflated. The purpose of this was to confirm that the marked tumor was located in the target segments. Next, the target bronchus was transected with the cutting stapler. The distal bronchial stump of the target segment was lifted cranially, and, after similarly careful identification, the deeper segmental arteries were dissected and transected with the endo stapler. The contour of the target segment was demarcated by segmental lung inflation and deflation. Finally, the endoscopic stapler was used for cutting the segmental plane. The segmental specimen was placed in a glove and removed through utility incision. The resection of this pulmonary segment proceeded from the caudal to the cranial direction. The most superficial segmental vein was transected first, along with the deep bronchus and deeper segmental artery, and finally the intersegmental plane in turn. The subsequent hilar and mediastinal lymph node sampling was performed.

Comments

Identifying the segmental bronchus and vessels that are involved in complicated anatomical variations is technically meticulous. Preoperative three-dimensional CT bronchography and angiography (3D-CTBA) can reveal anatomical structures and variations and can thus improve the accuracy of operation (11-13). In cases when identifying a targeted segmental structure by high-resolution CT proves difficult, we implemented 3D-CTBA to identify the targeted vessels, bronchus, and surgical margin preoperatively. Using the identification of the adjacent structures with less anatomic variation as a reference point, such as the dorsal segmental vein, and dorsal segmental bronchus, is another way of identifying a target structure during operation.

Basilar segmentectomy usually starts from the opening of the oblique fissure for the isolation of the superior and basilar branches of the lower lobe artery. However, the oblique fissure may be severely hypoplastic. By approaching the inferior pulmonary ligament, basal segmental structures can be reached more freely for dissection.

Due to there being no actual fissures among the segments, another difficulty of thoracoscopic segmentectomy is the dissection of the segmental vessels and bronchi which are located deep in the parenchyma. In our opinion, segmentectomy can be considered as a lobectomy with completely fused fissures. Therefore, the single-direction strategy which prevents the difficulty of a hypoplastic lung fissure is a suitable method for segmentectomy. The resection procedures at the hilum are carried out in a mining-like fashion, with the segmental vessels and bronchus being managed one by one, layer by layer. Additionally, it is easy to divide the intersegmental plane with a stapler as the last step since the segmental vessels and bronchus have already been transected.

In summary, VATS S9+10 segmentectomy could be successfully implemented with the strategy of single-direction through inferior pulmonary ligament approach.

Acknowledgements

Funding: This study was supported by the Key Science and Technology Program of Sichuan Province, People’s Republic of China (2016FZ0118 to Dr. L Liu).

Footnote

Conflicts of Interest: The authors have no conflicts of interest to declare.

Informed Consent: Written informed consent was obtained from the patient for publication of this manuscript and any accompanying images.

References

1. Aberle DR, Adams AM, Berg CD, et al. Reduced lung-cancer mortality with low-dose computed tomographic screening. N Engl J Med 2011;365:395-409. [Crossref] [PubMed]
2. Ginsberg RJ, Rubinstein LV. Randomized trial of lobectomy versus limited resection for T1 N0 non-small cell lung cancer. Lung Cancer Study Group. Ann Thorac Surg 1995;60:615-22; discussion 622-3. [Crossref] [PubMed]
3. Wisnivesky JP, Henschke CI, Swanson S, et al. Limited resection for the treatment of patients with stage IA lung cancer. Ann Surg 2010;251:550-4. [Crossref] [PubMed]
4. Kates M, Swanson S, Wisnivesky JP. Survival following lobectomy and limited resection for the treatment of stage I non-small cell lung cancer <=1 cm in size: a review of SEER data. Chest 2011;139:491-6. [Crossref] [PubMed]
5. Okada M, Yoshikawa K, Hatta T, et al. Is segmentectomy with lymph node assessment an alternative to lobectomy for non-small cell lung cancer of 2 cm or smaller? Ann Thorac Surg 2001;71:956-60; discussion 961. [Crossref] [PubMed]
6. Koike T, Yamato Y, Yoshiya K, et al. Intentional limited pulmonary resection for peripheral T1 N0 M0 small-sized lung cancer. J Thorac Cardiovasc Surg 2003;125:924-8. [Crossref] [PubMed]
7. Okada M, Koike T, Higashiyama M, et al. Radical sublobar resection for small-sized non-small cell lung cancer: a multicenter study. J Thorac Cardiovasc Surg 2006;132:769-75. [Crossref] [PubMed]
8. Jensik RJ, Faber LP, Milloy FJ, et al. Segmental resection for lung cancer: A fifteen year experience. J Thorac Cardiovasc Surg 1973;66:563-72. [PubMed]
9. Liu L, Che G, Pu Q, et al. A new concept of endoscopic lung cancer resection: Single-direction thoracoscopic lobectomy. Surg Oncol 2010;19:e71-7. [Crossref] [PubMed]
10. Zhu Y, Pu Q, Liu L. The video depicts a single-direction VATS left S9+10 segmentectomy. The operation was carried out with the single-direction strategy by approaching the inferior pulmonary ligament. The most superficial segmental vein was transected first, followed by the deep bronchi and deeper segmental artery, and the intersegmental fissure was treated last. Asvide 2018;5:866. Available online: http://www.asvide.com/article/view/28463
11. Eguchi T, Takasuna K, Kitazawa A, et al. Threedimensional imaging navigation during a lung segmentectomy using an iPad. Eur J Cardiothorac Surg 2012;41:893-7. [Crossref] [PubMed]
12. Iwano S, Yokoi K, Taniguchi T, et al. Planning of segmentectomy using three-dimensional computed tomography angiography with a virtual safety margin: technique and initial experience. Lung Cancer 2013;81:410-5. [Crossref] [PubMed]
13. Chan EG, Landreneau JR, Schuchert MJ, et al. Preoperative (3-dimensional) computed tomography lung reconstruction before anatomic segmentectomy or lobectomy for stage I non-small cell lung cancer. J Thorac Cardiovasc Surg 2015;150:523-8. [Crossref] [PubMed]
