Unexpectedly long intravenous and intracardiac extension of a small-sized pulmonary pleomorphic carcinoma

Introduction

Secondary cardiac malignancies, especially symptomatic ones, are uncommon, serious conditions. The routes by which neoplasms spread to the heart include direct invasion, hematogenous metastasis, lymphatic metastasis and transvenous extension. As for transvenous extension, renal cell carcinoma and hepatocellular carcinoma sometimes extend into the inferior vena cava and grow into the right atrium (1,2), but intracardiac extension of lung cancers via the pulmonary vein is rare, particularly when the lung tumor is small-sized and distant from the heart.

According to the 2004 World Health Organization (WHO) classification of the lung tumors (3), sarcomatoid carcinoma group of the lung are classified into five types: pleomorphic carcinoma, spindle cell carcinoma, giant cell carcinoma, carcinosarcoma and pulmonary blastoma. These neoplasms are uncommon histological types of lung carcinomas, comprising 0.3-1.3% of all pulmonary malignancies (3). Pleomorphic carcinoma is defined as squamous cell carcinoma, adenocarcinoma or large cell carcinoma containing spindle cells and/or giant cells, or carcinoma consisting only of spindle and giant cells. On the other hand, non-small cell carcinoma consisting only of spindle cells is called spindle cell carcinoma, and non-small cell carcinoma composed only of giant cells is named giant cell carcinoma. The behavior of tumors of this group is reported to be more aggressive than conventional non-small cell lung carcinomas (4-6).

Here we report a case of a pulmonary pleomorphic carcinoma of small size which showed unexpectedly long intravenous extension to the left atrium, resulting in fatal obstruction of the mitral valve.

Case report

A 64-year-old male was admitted to the hospital because of dyspnea at rest and fever. He reported a history of 10-kg weight loss for six months, cough for two weeks, and fatigue, dysphagia and muscle weakness for one week. He smoked three packs of cigarettes per day for over 40 years. On admission, the height was 167 cm and the weight 55 kg, the blood pressure 97/70 mmHg, the pulse 115 beats per minute, the temperature 37.1 degree C and SpO₂ 92%. Chest radiograph showed pulmonary congestion and opacity in the right upper lung (Figure 1A). Chest CT scan revealed opacity in the right upper lung with a tumor of approximately two cm in diameter in it (Figure 1B). Electrocardiogram showed no specific abnormality. Treatment with antibiotics and oxygen were started but his condition and respiration was progressively worsened next four days. Echocardiogram on third hospital day showed a large mass in the left atrium that caused obstruction of the mitral inflow of left ventricle (Figure 1C). Surgical removal of the mass was not selected because of his condition. He died of cardiac inflow obstruction four days after the admission. An autopsy was performed.

Figure 1 (A) Chest radiograph showed congestion of the bilateral lungs and opacity in the right upper lung; (B) chest CT scan revealed a nodule (arrow) of approximately two cm in diameter with opacity in the upper lobe of the right lung; (C) echocardiography showed a large mass (arrows) in the left atrium, causing obstruction of the mitral valve. Ao, aorta; LA, left atrium; LV, left ventricle; RA, right atrium; RV, right ventricle.

Grossly, a white, well-circumscribed nodule of 22 mm in diameter was found in the peripheral region of the upper lobe of the right lung (Figure 2A). The tumor showed direct invasion to the pulmonary vein branch (Figure 2B), and the tumor tissue extended intravenously and continuously from the lung nodule to the left atrium through the superior right pulmonary vein (Figure 2C,D). The distance between the lung nodule and the left atrium was approximately ten cm, and therefore the tumor tissue was elongated for this distance intravenously. In the lumen of the left atrium, the tumor tissue formed a mass of 8 cm × 5 cm × 3 cm (Figure 2E). The surface of the mass facing the mitral valve was indented as a mold of the shape of the mitral cusps (Figure 2F), suggesting that the mass obstructed the mitral valve. The morphology of the mitral valve itself was almost normal. Neither distant metastasis nor nodal involvement was observed. Systemic embolism of the tumor fragments was not found.

Figure 2 Gross findings of the lung tumor (A-D) and intracardiac tumor (E,F). A white, well-circumscribed nodule of 22 mm in diameter was found in the upper lobe of the right lung (A). The neighboring section (B) showed direct invasion of the tumor to the pulmonary vein branch. The intravenous component of the tumor extended from the nodule (B) to the pulmonary hilum (C), and finally into the left atrium (D). Arrowheads (A-D) indicate intravenous extension of the tumor. B and C in (D) correspond to the sections of (B) and (C), respectively. (E) A mass of 8 cm × 5 cm × 3 cm (arrowheads) was found in the left atrium, which was continuous with the intravenous component of the lung tumor in the superior right pulmonary vein. (F) The surface of the intraatrial mass facing the mitral valve (arrow) was indented as a mold of the shape of the mitral cusps. LA, left atrium; LV, left ventricle; MV, mitral valve; RL, lower lobe of right lung; RU, upper lobe of right lung; SRPV, junction of superior right pulmonary vein and left atrium.

Histologically, the lung nodule as well as the intravenous and intraatrial portion of the tumor was composed of atypical spindle cells and giant cells (Figure 3A,B). Neutrophil infiltration was observed. Component of conventional non-small cell lung carcinoma (squamous cell, adeno-, or large cell carcinoma) was not found. Immunohistochemically, the spindle and giant cells were positive for cytokeratin AE1/AE3 (Figure 3C) and cytokeratin 7, and a small number of these cells were positive for TTF-1 (Figure 3D). These cells were negative for cytokeratin 20. Mallory-azan stain (which stains fibrous tissue blue) (Figure 3E) and CD34 immunostain (an endothelial marker) (Figure 3F) revealed that the tumor tissue had scant fibrous stroma and abundant small blood vessels, respectively. These findings indicate that the tumor was pleomorphic carcinoma of the lung with marked intravenous extension to the left atrium, resulting in fatal obstruction of the mitral valve. The non-neoplastic lung tissue around the nodule of the right upper lobe showed congestion and edema with marked intra-alveolar fibrin and organization. Mild emphysema was also found.

Figure 3 Histological findings of the lung tumor. Microscopically, low-power (A) and high-power (B) views of the lung nodule revealed that it was composed of atypical spindle and giant cells with neutrophil infiltration (hematoxylin-eosin stain). Immunohistochemically, the tumor cells were positive for cytokeratin AE1/AE3 (C) and TTF-1 (D, arrows). Mallory-azan stain showed that the tumor tissue had scant fibrous stroma (E), and immunostain for CD34 demonstrated numerous blood vessels in the tumor tissue (F). Scale bars for A, 250 μm; for B-D, 50 μm; for E and F, 100 μm.

Discussion

In the present case, one of the clinical problems was the relation between the intracardiac mass and lung nodule detected by echocardiography and chest CT, respectively. Several hypotheses were considered: these tumors might be independent primaries; the former might be metastasis of the latter, and vice versa; both of them might be metastasis of an unknown primary neoplasm. At autopsy, the continuity of these two tumors via the pulmonary vein, and immunoreactivity to TTF-1 (a specific marker for primary lung carcinoma) and cytokeratin clearly indicated that the lung nodule was the primary site and the intracardiac mass was the leading edge of endovascular extension of the carcinoma.

Pleomorphic carcinoma is a rare histological type of lung carcinoma. Patients of pleomorphic carcinoma are reported to be predominantly male smokers with a mean age of 66 years (4-7). It tends to arise as a peripheral mass with a predilection for the upper lobes (5,7). The clinical course of this tumor is reported to be aggressive, compared to conventional non-small cell lung carcinomas (4-6). Histologically, pleomorphic carcinoma can be divided into two subgroups: (I) a conventional non-small cell carcinoma admixed with malignant spindle cells and/or giant cells; and (II) a carcinoma composed only of malignant spindle and giant cells. The present case corresponds to the subgroup (II), and the patient’s age, smoking habit and location of the lung tumor are thought to be typical of pleomorphic carcinoma.

Intravenous extension to the left atrium is a rare complication of lung carcinomas, and several cases including small cell carcinoma (8,9) and conventional non-small cell carcinomas (10-14) were reported previously. Among them, intracardiac extension of sarcomatoid carcinoma group is extremely rare, and only one case of giant cell carcinoma (10) and one case of pleomorphic carcinoma composed of adenocarcinoma and spindle-cell components [subgroup (I), see above] (15) were described (Table 1). Thus, our paper is the second report of pulmonary pleomorphic carcinoma extending intravenously to the left atrium.

Table 1 Reported cases of sarcomatoid carcinoma group of the lung with intravenous extension to the left atrium
Full table

As shown in Table 1, common symptoms of these patients include weight loss and cough, which probably resulted from the lung tumor itself. Dyspnea, palpitations and arrhythmia might represent signs caused by an intracardiac tumor. The present case showed these common symptoms including dyspnea while muscle weakness, the pathophysiology of which was not clear, was a peculiar symptom to this case.

In the previously reported cases of sarcomatoid carcinomas (Table 1) and other histological types (8-14), the primary tumors in the lungs were advanced, large masses and therefore invaded near the heart. However, one of the remarkable findings of the present case is disproportionately long intravenous extension compared to the small size of the lung tumor. In fact, the lung tumor of the present case is much smaller than the previous cases (Table 1), and the intravenous component of the present tumor running from the lung nodule to the left atrium is markedly long (approximately 10 cm in length). This made clinical diagnosis difficult because the lung tumor was so distant from the heart that the intracardiac extension of the lung tumor seemed very unlikely. The histological features of the present tumor might explain this unexpectedly long extension in the pulmonary vein. First, the histological type of the lung cancer is pleomorphic carcinoma, which is biologically more aggressive than ordinary non-small cell carcinomas. Secondly, the tumor tissue had abundant blood vessels and lacked desmoplasia, which might facilitate smooth elongation in the venous lumen without necrotic collapse of the tumor tissue or hard adhesion to the surrounding structure. Hypervascularity and scant fibroplasia are shared features of other cancers with high propensity for intravenous extension, for example, hepatocellular carcinoma and renal cell carcinoma.

In summary, the present case teaches us that when a patient with a lung carcinoma even of a small size and located distantly from the heart presents with dyspnea, we should consider the possibility of intracardiac extension of the pulmonary neoplasm.
