Assessment of intrathoracic lymph nodes by FDG PET/CT in patients with asbestos-related lung cancer

Introduction

The diagnosis of hilar and mediastinal lymph node metastases in primary lung cancer is important for determining the indications for surgery, surgical techniques, and treatment options, including chemotherapy and radiation therapy. ¹⁸F-fluoro-2-deoxy-D-glucose (FDG) positron emission tomography (PET) computed tomography (CT) is generally performed for nodal and systemic evaluation in conjunction with enhanced CT as a non-invasive modality. However, increased false-positive (FP) findings combined with pneumoconiosis, such as silicosis, may occur.

Asbestos is an occupational dust that causes lung cancer and malignant pleural mesothelioma. There are limited clinicopathological studies on asbestos-related lung cancer (ARLC), and mediastinal lymph node evaluation by FDG-PET/CT in patients with ARLC has not been reported. Thus, this study explored the accuracy of FDG-PET/CT for intrathoracic lymph node assessment in patients with ARLC compared to that of surgical and histological findings.

We present the following article in accordance with the STROBE reporting checklist (available at https://dx.doi.org/10.21037/jtd-21-974).

Methods

Patients and data collection

In Japan, the definition of ARLC is primary lung cancer with (I) asbestosis on chest radiography; (II) pleural plaques with >10 years of occupational asbestos exposure; (III) asbestos particles or fibers on the lung tissues with >10 years of occupational asbestos exposure; and (IV) >5,000 asbestos bodies per gram of dry lung tissue with occupational asbestos exposure (1).

This study included 35 patients with ARLC who underwent preoperative FDG-PET/CT and surgical resection between January 2012 and December 2018. We collected information from medical records and imaging systems and examined FDG accumulation in lymph node regions resected by surgery and the presence or absence of pathological lymph node metastasis. This retrospective observational study was conducted in accordance with the Declaration of Helsinki (as revised in 2013), and approved by our institutional review board (approval no. 167; approval date: February 29, 2019). Informed consent was waived because of the anonymous nature of the data.

FDG-PET/CT image analysis

FDG-PET/CT was performed in two medical institutions by their radiologists and in our institution by two thoracic surgeons. Intrathoracic lymph node stations were assessed according to the International Association for the Study of Lung Cancer lymph node map (2). Intrathoracic lymph nodes with focally increased FDG uptake, excluding physiologic uptake, compared to that in the surrounding normal tissue were considered positive.

Surgery and histopathology

All patients underwent standard hilar and mediastinal lymph node resection and pulmonary resection, including lobectomy and segmentectomy. The surgeons labeled the dissected lymph nodes by numbering them according to the lymph node map. Pathological review (primary tumor characteristics and lymph node status) was performed using standard techniques, and immunohistochemistry was used when appropriate.

Statistical analysis

FDG-PET/CT findings were compared to histological findings in the resected lymph node stations. Each lymph node station was classified as true positive (TP), true negative, FP, or false negative. All calculations and statistical tests were performed using StatMate version 5 (ATMS Publishing, Japan). The continuous variables were expressed as median [interquartile range (IQR) 25th–75th percentile]. The categorical data were expressed as counts and proportions. The continuous variables were checked using the Mann-Whitney test, while the categorical variables were evaluated using the Fisher’s exact test. P values <0.05 were considered statistically significant.

Data analysis

The FDG-PET/CT findings were compared to the histological findings in the resected lymph node stations to determine their diagnostic sensitivity and specificity. The sensitivity, specificity, and accuracy of integrated PET/CT in the assessment of intrathoracic lymph node involvement were determined using histological findings as the reference standard.

Results

Pathology and nodal staging

The characteristics of the enrolled patients are shown in Table 1. The study group included 35 men with a mean age of 73 years [interquartile range (IQR): 70–78]. All patients had been exposed to asbestos but not to coal or silica; chest CT showed no evidence of asbestosis and no history of inflammatory lung diseases such as interstitial pneumonia or tuberculosis. The median smoking index was 800, and 22 patients (62.9%) were heavy smokers with smoking indices of >600. Asbestos bodies per gram of dry lung tissue representing asbestos exposure ranged from 6,039 to 61,097 (interquartile range), with a median of 13,061.

Regarding occupational histories, 13 worked in dockyards, five in the construction industry, five in pipework, followed by brickyards and others, which are shown in Table 2. In this study, 25 (71.4%) patients had adenocarcinoma and 8 (22.9%) patients had squamous cell carcinoma. A total of 161 lymph node stations were dissected, including 18 superior mediastinal, 13 aortic, 32 inferior mediastinal, and 98 N1 lymph nodes. Pathological lymph node metastases were detected in 14 (8.70%) of 161 nodal stations (Tables 3,4).

PET/CT correctly detected 10 metastatic lymph node stations (71.4%; nine N1 and one N2). False-negative results were observed in four nodal stations (one N1 and three N2) and false-positive results were observed in 18 nodal stations (four N1 and 14 N2). The relationships between PET/CT lymph node evaluation and pathology at each station are shown in Tables 3,4. The overall sensitivity, specificity, positive predictive value, negative predictive value, and accuracy of FDG-PET/CT were 71.4% (10/14), 87.8% (129/147), 35.7% (10/28), 97.0% (129/133), and 86.3% (139/161), respectively.

Characteristics of the false-positive lymph nodes

The occupational history of the eight patients with false-positive lymph nodes included four dockyards, one brickwork, one electrical work, one casting, and one pipework. Eighteen false-positive nodal stations were identified from eight patients, including 14 N1, 2 superior mediastinal, 1 aortic, and 1 inferior mediastinal lymph nodes. The short diameter of the lymph nodes on chest CT ranged from 5.3 to 6.7 mm (interquartile range), with a median of 6.3 mm. Lymphadenopathy exceeding 10 mm in short diameter was observed in only 1 of the 18 stations (Tables 5,6). Histopathological examination of the FP nodes showed disruption of the lymphoid follicles in the cortex, infiltration of histiocyte-like cells in the medulla, fibrous micronodules, and severe anthracosis (Figure 1). No calcifications were observed. Lymphoid follicular hyperplasia and histiocyte infiltration have been reported as causes of increased FDG uptake in benign mediastinal LNs (3); thus, Glut-1 and CD-68 staining was performed in FP cases on PET/CT. However, immunohistochemical examination revealed equivocal Glut-1 staining in the lymph node cortex compared to that in positive control erythrocytes and CD-68-negative staining of the histiocyte-like cells in the lymph node medulla. All patients with PET FP lymph nodes exhibited severe anthracosis (Tables 5,6).

Figure 1 Histological findings of resected lymph nodes with PET false-positive results. (A) Histological section of a false-positive lymph node (H&E staining, ×12.5). (B) Histology showing fibrous nodule formation, anthracotic pigmentation in the medulla, and disruption of lymphoid follicles in the cortex (H&E staining, ×40). (C) Immunostaining for GLUT-1 showing equivocal staining of the cortex area, except for the erythroblasts (×200). (D) Histiocytic-like cells with anthracotic pigmentation showing CD-68-negative staining (×200).

Comparison of characteristics between the false-positive and true-positive lymph nodes

The clinical characteristics were compared between patients with FP and TP lymph nodes (Table 7). Six of eight FP cases had bilateral accumulations, whereas all six TP cases had unilateral accumulation (P=0.006). There was no significant difference in the size of the dissected PET FP and PET TP lymph nodes, but the short diameter on chest CT was significantly larger in PET TP lymph nodes (P=0.008). The median asbestos concentrations were 12,508/g dry lung (IQR: 9,666–94,474) in the FP group and 16,452/g dry lung (IQR: 7,448–65,249) in the TP group, with no significant difference between the groups (P=0.747). Similarly, there were no significant differences in smoking between the TP and FP groups (P=0.796).

Discussion

The present study explored the assessment of intrathoracic lymph node metastasis using FDG-PET/CT in patients with ARLC. Previous studies have proposed integrated PET/CT as a better modality for evaluating lymph nodes and distant metastasis (4-8). However, FDG-PET/CT has a high false-positive rate in the assessment of mediastinal lymph nodes in patients with lung cancer and those with some concomitant benign conditions such as infection, granulomatous lesions, and pneumoconiosis (9-12).

This study focused on occupational dust and asbestos-related lung cancer. Asbestos is carcinogenic dust that causes pleural mesothelioma and lung cancer (13). Inhalation of asbestos results in a 50-fold increased risk of lung cancer among smokers (14). Silicosis and coal-workers pneumoconiosis are on a decreasing trend in Japan, but ARLC has a long latent period of about 20 years from asbestos exposure to the onset of disease (13). It is an occupational dust disease that will continue to increase in the future, although the use, manufacture, and import of asbestos were abolished in Japan in 2006. Nevertheless, the clinicopathological features of ARLC are not well known. Although previous studies have demonstrated the usefulness of PET/CT for the preoperative diagnosis of lung cancer, no studies have examined its sensitivity, specificity, or accuracy in ARLC. Thus, we conducted this study to explore the assessment of intrathoracic lymph node metastasis using FDG-PET/CT in patients with ARLC.

In the current study, the sensitivity, specificity, and accuracy of FDG-PET/CT for hilar and mediastinal lymph nodes in patients with ARLC were 71.4%, 87.8%, and 86.3%, respectively. In their meta-analysis, Pak et al. (5) reported that PET/CT had a pooled sensitivity and specificity of 62% (widely ranging from 13% to 98%) and 92% (ranging from 72% to 98%), respectively. The accuracy of FDG-PET/CT in patients with ARLC was within the range reported in the literature. Regarding lung cancer with occupational dust diseases as the underlying disease, the sensitivity, specificity, and accuracy of PET/CT in patients with lung cancer among coal workers were 84%, 65%, and 74%, respectively (15). The lymph node FP rate in patients with ARLC was lower than that in coal workers with lung cancer (12.2% vs. 35%). Regarding the cause of FP lymph nodes in patients with ARLC, there are no underlying diseases such as calcification of the lymph nodes, granulomatous diseases including tuberculosis, or pulmonary diseases such as interstitial pneumonia.

The histological findings of FP lymph nodes included disruption of lymphoid follicles in the cortex, infiltration of histiocyte-like cells, fibrous nodules, and severe anthracosis in the medulla. Shim et al. reported that FP lymph nodes showed calcification, follicular hyperplasia in the cortex, macrophage infiltration with anthracotic pigmentation, and fibrotic nodule formation in the medulla (16). Calcification and lymphoid follicular hyperplasia were not observed in the present study. In addition, Glut-1 and CD 68 staining also revealed negative findings, although some studies have reported lymphoid follicular hyperplasia and histiocytic infiltration in FP nodes. Furthermore, Glut-1 overexpression is associated with FDG uptake (3,17). The negative staining for Glut-1 may explain the disruption of lymphoid follicle in the cortex. Anthracosis and silico-anthracosis have been reported as other causes of false-positive PET results in hilar and mediastinal lymph nodes (18-20). The occupational history of the eight patients with false-positive lymph nodes in these cases included four dockyards, one brickwork, one electrical work, one casting, and one pipework, all of whom had work environments where exposure to carbon dust inhalation was suspected in addition to asbestos inhalation. The main factor of FDG uptake in these cases may be related to severe anthracosis rather than lymphoid follicular hyperplasia or histiocytic infiltration.

FP lymph node findings affect treatment plans for lung cancer as mediastinal lymph node metastasis requires consideration of the operative indications, whether the primary treatment is surgery or not, while N1 lymph node metastasis requires consideration of the operative methods regarding the need for bronchoplasty or pulmonary angioplasty. In this study, six of eight FP lymph nodes had bilaterally symmetrical accumulations. The clinical features of FP lymph nodes in ARLC include bilaterally symmetric accumulations, similar to those in FP nodes in other diseases (21). Thus, the sensitivity and specificity can be improved and this method may be applied for the preoperative evaluation of lymph node metastasis, as in the case of ordinary lung cancer. This study has several limitations. Because ARLC is rare and there are few cases of FP lymph nodes, further case series are needed to investigate the histological features of FP lymph nodes in ARLC.

In our study, the sensitivity and specificity rates of FDG-PET/CT for ARLC for the assessment of hilar and mediastinal lymph node metastasis were 71.4% and 87.8%, respectively. PET/CT scans of patients with ARLC had comparable sensitivity and specificity to those of PET/CT scans of patients with conventional lung cancer reported in the literature. Many FP cases also showed bilateral symmetric accumulation. This method can be used to evaluate lymph node involvement in lung cancer.

Acknowledgments

We would like to thank Editage (www.editage.com) for English language editing.

Funding: None.

Footnote

Reporting Checklist: The authors have completed the STROBE reporting checklist. Available at https://dx.doi.org/10.21037/jtd-21-974

Data Sharing Statement: Available at https://dx.doi.org/10.21037/jtd-21-974

Peer Review File: Available at https://dx.doi.org/10.21037/jtd-21-974

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at https://dx.doi.org/10.21037/jtd-21-974). The authors have no conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. This retrospective observational study was conducted in accordance with the Declaration of Helsinki (as revised in 2013), and approved by our institutional review board (approval no. 167; approval date: February 29, 2019). Informed consent was waived because of the anonymous nature of the data.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.
