Surgical treatment of empyema after pulmonary resection using pedicle skeletal muscle plombage, thoracoplasty, and continuous cavity ablution procedures: a report on three cases

Noriaki Sakakura1,2, Tetsuya Mizuno1, Hiroaki Kuroda1, Yukinori Sakao1, Tatsuo Uchida2

1Department of Thoracic Surgery, Aichi Cancer Center Hospital, Nagoya, Japan; 2Department of Thoracic Surgery, Aichi Cancer Center Aichi Hospital, Okazaki, Japan

Correspondence to: Noriaki Sakakura, MD. Department of Thoracic Surgery, Aichi Cancer Center Hospital, Nagoya, 1-1 Kanokoden, Chikusa-ku Nagoya 464-8681, Japan. Email:

Abstract: We present three cases of postoperative empyema after pulmonary resection: case 1, acute empyema without fistula after lobectomy and chest wall resection; case 2, continuing empyema with fistula and total left residual lung abscess after upper divisionectomy; and case 3, chronic empyema with middle lobe bronchopleural fistula after lower lobectomy. Pedicle skeletal muscle plombage into the cavity, thoracoplasty, and continuous cavity ablution with 24-h instillation of minocycline and saline solution through drains were used for treatment. In case 2, a completion extrapleural left pneumonectomy was concurrently performed. In all three cases, the surgery was successful; however, case 2 developed a massive gastrointestinal hemorrhage, which led to blood aspiration pneumonitis, renal failure, and death. Muscle plombage effectively achieves the closure of empyema cavity and thoracoplasty complements this. When a residual space remains, cavity ablution is considered to be effective. However, concurrent completion lung parenchyma resection might be excessively aggressive.

Keywords: Pulmonary resection; empyema; thoracoplasty; muscle plombage; cavity ablution

Submitted Feb 05, 2016. Accepted for publication Mar 01, 2016.

doi: 10.21037/jtd.2016.04.04


Empyema after pulmonary resection is a serious complication and treatment is often extremely difficult (1-5). To cure empyema, closure of the fistula and abscess cavity is crucial; therefore, the transplantation of omentum or skeletal muscles is often performed. General thoracic surgeons have recently encountered fewer cases of inflammatory pulmonary disease; therefore, for each case, the postoperative empyema management is conducted through a trial and error process. Here we present three cases of postoperative acute empyema without fistula, continuing empyema with fistula, and chronic empyema with fistula, respectively, that were all treated by a combination of pedicle skeletal muscle plombage, thoracoplasty, and continuous cavity ablution. Cases 1 and 2 were treated at the Aichi Cancer Center Aichi Hospital (Okazaki, Japan) and case 3 was managed at the Aichi Cancer Center Hospital (Nagoya, Japan).

Case presentations

Case 1

This patient was a 70-year-old male with diabetes and emphysema. He had squamous cell carcinoma of the lung originating from the right upper lobe. He was diagnosed as having cT3N0M0 stage IIB disease with a 6-cm tumor infiltrating the second and third ribs along the anterior axillary line. Induction treatment included cisplatin and vinorelbine administration as well as concurrent radiation therapy at 40 Gy. Surgery was performed 1 month after the induction therapy. The second to the fourth ribs were resected through a 9 cm × 8 cm area via anteroaxillary thoracotomy, followed by right upper lobectomy. The bronchial stump was covered by mediastinal fat tissue, and the chest wall was reconstructed using a Gore-Tex® dual mesh (2 mm, Gore Company, USA). The patient developed fever 7 days after surgery and was diagnosed with empyema. The bacterium was methicillin-resistant Staphylococcus epidermidis, which was treated with vancomycin. Because his physical condition was not stable and another thoracotomy would have been difficult, drainage was continued for 3 weeks while his recovery was monitored. Residual lung expansion was inadequate and a large space remained (Figure 1A).

Figure 1 Case 1. (A) A large dead space is observed in the chest cavity; (B) the bundle of the pedicle from the LD and SA muscles was raised; (C) the muscles were subcutaneously introduced into the anterior part of the thorax; (D) two 19-Fr (inflow) and two 24-Fr (outflow, arrows indicating flow) elastic drains were placed at both the mediastinal and surface sides for cavity ablution. LD, Latissimus dorsi; SA, serratus anterior.

Surgery to cure the empyema was performed 4 weeks after the initial surgery. We removed the mesh and performed debridement and decortication of the empyema cavity. The bronchial stump was fully covered by the pedicle of the mediastinal fat tissue and no bronchopleural fistula was present. Because remaining lung re-expansion was not expected and the chest wall defect would depress owing to the empyema cavity being the size of two fists, muscle plombage was considered to be an effective procedure. A 14-cm long incision was made in the cranial-to-caudal direction directly on top of the latissimus dorsi (LD) muscle, and a 25 cm × 15 cm portion of the pedicle from the LD and serratus anterior (SA) muscles was raised (Figure 1B) preserving the thoracodorsal neurovascular bundle located between the two muscles. The raised portion was then subcutaneously introduced into the empyema cavity (Figure 1C). For cavity ablution and drainage, two 19-Fr (inflow) and two 24-Fr (outflow) elastic drains (Blake, Ethicon Co., USA) were inserted into the mediastinal and surface sides (Figure 1D). Continuous ablution was performed by 200 mg minocycline and 1000 mL saline solution administration for 24 h. The drainage fluid was cultured three times. The first culture was positive for bacteria, whereas subsequent cultures were negative. After 5 days of continuous washing, all drains were removed by the 7th day. The patient recovered well and was released from hospital 3 weeks after the empyema surgery.

Case 2

This patient was a 70-year-old male with emphysema and history of partial gastric resection. He underwent left upper divisionectomy for a pneumothorax secondary to the emphysema. After 6 months, the pleural effusion in the cavity had disappeared, and a small aerial fistula was suspected. His chest condition was monitored in the outpatient department. Two years after the surgery, he developed respiratory failure and had to be hospitalized. At this point, fluid had accumulated in the left thoracic cavity, and he presented with pneumonia of the total left residual lung. First, open-window thoracostomy was performed by removing the second and third ribs in the anterior chest. A gray purulent fluid and few bronchial fistulae on the surface of the residual lung parenchyma were observed. Culture of the pus revealed combined infection of Aspergillus fumigatus and Stenotrophomonas maltophilia. Sensitive antibiotics, such as voriconazole, were administered, and intravenous hyperalimentation and rehabilitation were prescribed. Thereafter, the empyema cavity was gradually purified; however, the left lung did not improve and progressed to a chronic abscess of the total left residual lung (Figure 2A,B).

Figure 2 Case 2. (A,B) Chronic total left residual lung abscess after left upper divisionectomy and open-window thoracostomy; (C) the pedicle of the LD and SA muscles was harvested via a large posterolateral incision; (D) intraoperative view after completion extrapleural pneumonectomy, thoracoplasty, and muscle plombage to the left thorax. LD, Latissimus dorsi; SA, serratus anterior.

Five months after the thoracostomy, a curative operation, which comprised completion extrapleural left pneumonectomy, muscle plombage, and thoracoplasty, was performed. Because the mediastinum was shifted to the left, the pericardium was approached at a distance of two thumb widths to the left of the mediastinum, and the left main pulmonary artery and bronchus were cut in the dorsal position. Next, the patient was turned to the right decubitus position, and a pedicle of the LD and SA muscles was harvested via a large posterolateral incision (Figure 2C). The fifth, sixth, and seventh ribs were removed, and completion partial extrapleural pneumonectomy was performed. Thoracoplasty for the removal of the fourth to eighth ribs, debridement of the empyema cavity, and muscle plombage to the left thoracic cavity were also performed. For continuous ablution, thoracic tubes were placed similar to those placed in case 1 (Figure 2D). The thoracostomy window was closed by gathering the surrounding tissue. There was 2,300 mL of blood loss, and the operating time was 19 h. Continuous ablution was performed for 24 h via two thoracic tubes by instillation of 100 mg minocycline and 500 mL saline solution into the thoracic cavity. The patient was recovering until 7 days after the surgery. Three separate cultures of the drain effusion revealed the absence of bacteria, the purulent sputum ceased, and he was expected to recover from the severe empyema and total left lung abscess. However, on the 8th day, he developed massive hematemesis and gastrointestinal hemorrhage. Endoscopic hemostasis was performed; however, on the following day, he developed hemorrhagic shock, blood aspiration pneumonitis of the right lung, and renal failure. Fourteen days after surgery, he died from multiple organ failure.

Case 3

This patient was a 59-year-old female who, 9 years previously, had undergone lower right lobectomy for a metastatic pulmonary tumor originating in the tongue. She was hospitalized as an emergency case after worsening respiratory failure and 3 months of fever. Accumulation of pleural effusion and the presence of a space were confirmed in the right thorax (Figure 3A). After inserting a drainage tube, purulent effusion and air leaks were confirmed. The infecting microorganisms were a mix of Friedlander bacillus, anaerobic bacteria, and Candida, and she was diagnosed as having empyema with fistula. Drainage and appropriate antibiotic administration for 2 weeks rendered the effusion free of microbes. On imaging studies, two bronchioles with fistulae were observed in the middle lobe. The space was large, indicating the need to perform an open window thoracostomy; however, because the empyema cavity was free of microbes and her physical condition was good, we opted for surgical closure of the fistula and cavity.

Figure 3 Case 3. (A) A large empyema cavity after right lower lobectomy performed 9 years earlier; (B) LD, SA, and the bundle of pedicle from the 6–7th intercostal (I) muscles harvested via an alteration of vertical muscle sparing incision; (C) muscle plombage to the cavity; (D) the muscles engrafted to the cavity completely filled the thoracic space. LD, Latissimus dorsi; SA, serratus anterior.

The curative surgery was performed with an alteration of the vertical muscle sparing incision, preserving the LD muscle. After harvesting a pedicle of the LD muscle, the SA muscle was raised. The eighth and ninth ribs were removed, followed by the sixth and seventh ribs. Subsequently, a bundle of pedicle from the 6–7th intercostal muscles was raised (Figure 3B). After debridement, the bronchial fistulae were closed by sewing the muscles to the fistula and plombage to the cavity (Figure 3C). Similar to cases 1 and 2, continuous ablution via thoracic tubes was performed for 5 days. Postoperative infection was not exacerbated, and the patient was released from hospital 3 weeks after surgery. One year after surgery, the muscle engrafted to the cavity completely filled the space (Figure 3D).


Recently, general thoracic surgeons encounter fewer cases of inflammatory pulmonary disease. Sharing clinical experiences of postoperative empyema is important because, in many cases, it is difficult to manage. Various clinical conditions exist in cases of empyema, requiring case-specific or individualized treatment. In each of the three cases described above, the treatment that was considered as best suited for each patient was chosen; however, there are many points for reflection. Here we elaborate on the choices made and points for consideration in each case management, in particular, pedicle skeletal muscle plombage and continuous thoracic cavity ablution.

In case 1, it can be argued that once the empyema was confirmed, the chest wall artifact should have been removed instead of insertion of a drainage tube. The physical condition of this patient was poor because of chest wall resection after induction chemoradiotherapy; therefore, a second, immediate open-chest surgery was not desirable. Instead, it was decided to manage the recovery under drainage before the second open-chest surgery. Next, the use of muscle plombage over removal of the chest wall artifact and debridement may be questioned. The reasons for performing the muscle plombage procedure are that the bronchial stump covered by the mediastinal fat tissue faced into the empyema cavity, the cavity was large, the residual lung expansion was not expected, and the skin depression because of the chest wall defect was large.

In case 2, the patient had empyema with fistula complicated by residual lung abscess; this was a patient we could not rescue. How do you manage this critical condition? We regret that open-window thoracostomy could not be performed when the aerial fistula was small and only empyema was present. Although there are some reports on treating empyema with fistula by extrapleural pneumonectomy (3-5), these studies represent only successful cases and many other failed attempts may not have been reported. This patient’s general condition was poor because of hemorrhaging from the lung abscess and large amounts of purulent sputum. Because combined extrapleural pneumonectomy, muscle plombage, and thoracoplasty were performed at the same time, the nature of the surgery was excessively aggressive, and the patient did not survive the perioperative period. The attending surgeon (N.S.) consulted many experts (indicated in “Acknowledgements”) on the possibility of recovery after surgery, and as a result, many opinions, including those pertaining to the operability and suitability of the surgery, were raised. The patient’s preoperative Eastern Cooperative Oncology Group performance status was 3, and there was no other treatment option other than removal of the lung abscess. Because the empyema and lung abscess seemed to be controlled after surgery, there is a possibility that these procedures deserve consideration for the treatment of empyema with severe lung abscess. Intercostal arterial embolus or multistage surgery may also be considered to reduce the excessive invasiveness of multiple surgical procedures.

Case 3 represents a case in which primary closure would have been possible if sterility of the empyema cavity could have been attained, even when a chronic bronchopleural fistula existed. Another possible treatment was open-window surgery to reduce the empyema cavity followed by curative plastic surgery (2).

Regarding engrafting the pedicle soft tissue, the omentum is rich in blood and contains immune cells that enable wound healing in the defective site; alternatively, the aim of skeletal muscle plombage is to physically fill the empyema cavity (6). The proportion of thorax that can be closed by various types of pedicle muscle flaps is 30–40% for LD muscles, 20–30% for SA muscles, and 5–15% for abdominal rectus muscles (1,7). In case 1, the LD muscle fitted the empyema cavity that was the size of two fists after upper lobectomy. In case 2, although there were insufficient muscles to fill the entire thoracic cavity, the muscles filled two thirds of the thorax, and consecutive thoracoplasty by removing the ribs enabled us to achieve full plombage with only a small residual cavity. In case 3, a bundle of pedicle from the intercostal muscles was used in addition to the LD and SA muscles to achieve filling of the cavity. In all three cases, the LD muscle could be used because it was preserved in the first surgery. This reminded us of the importance of this muscle in cases of postoperative empyema. If the LD muscle has been cut, a retrograde muscle flap supplied by the posterior paraspinal perforating branch can be used, although the volume of muscle is smaller (8).

When deciding to perform muscle transplantation, consultation with a plastic surgeon who is familiar with the treatment of empyema is desirable; however, this is not always possible. Therefore, it is necessary for general thoracic surgeons to become familiar with these procedures. Simple pedicle transplants involving familiar muscle flaps, such as pectoralis major, LD, and SA muscles, can be performed using textbook explanations on empyema treatment (9).

There is no established method for purifying the thoracic cavity formed during empyema; however, compared with intravenous administration, the direct instillation of antibiotics sensitive to the causative bacteria may be more effective in the cavity (10). Considering that some space might have existed after muscle plombage, thoracic ablution was performed in all three cases. Minocycline is often used during pleurodesis, and we continuously administered it into the thoracic cavity after confirming its sensitivity to the causative microorganisms. Theoretically, if the cavity is too large, purification of the empyema cavity is difficult and ablution is considered to be effective when plombage has been performed to some extent. To further decrease the cavity, adequate thoracoplasty, which is sometimes considered to be excessively aggressive, is required.

Muscle plombage effectively achieves the closure of empyema cavity and thoracoplasty complements this. When a residual space remains, cavity ablution may be effective. However, deliberate consideration is required for procedures that include concurrent completion lung parenchyma resection, because such procedures might be excessively aggressive. Although we cannot always or easily perform these procedures in severe cases, the methods are applicable to a wide variety of conditions associated with empyema.


With respect to the treatment of case 2, we would like to thank Dr. Yoshiki Hiramatsu of the Toyota Kosei Hospital for his valuable advice and assistance during surgery. We would also like to thank Dr. Morihisa Kitano of the Aizawa Hospital, Dr. Kohei Yokoi of the Nagoya University Hospital, and Dr. Hironori Ishida and Dr. Hirozo Sakaguchi of the Saitama Medical University International Medical Center for their valuable advice, and Dr. Daisuke Tochii and Dr. Syuhei Ashikari of the Fujita Health University Hospital for assistance during surgery.


Conflicts of Interest: The authors have no conflicts of interest to declare.

Informed Consent: Each patient was informed that his clinical data could be used for various clinical studies, and written informed consent for this report was obtained on this basis.


  1. Miller JI, Mansour KA, Nahai F, et al. Single-stage complete muscle flap closure of the postpneumonectomy empyema space: a new method and possible solution to a disturbing complication. Ann Thorac Surg 1984;38:227-31. [Crossref] [PubMed]
  2. Thourani VH, Lancaster RT, Mansour KA, et al. Twenty-six years of experience with the modified eloesser flap. Ann Thorac Surg 2003;76:401-5. [Crossref] [PubMed]
  3. Utley JR. Completion pneumonectomy and thoracoplasty for bronchopleural fistula and fungal empyema. Ann Thorac Surg. 1993;55:672-6. [Crossref] [PubMed]
  4. Shiraishi Y, Katsuragi N, Kurai M, et al. Extrapleural completion pneumonectomy combined with chest wall resection for complex aspergilloma (in Japanese with English abstract). Kyobu Geka 2004;57:1039-42. (Jpn J Thorac Surg). [PubMed]
  5. Tokui T, Kaneda M, Hatanaka K, et al. Anterior approach for pleuropneumonectomy and thoracoplasty with chronic empynema; two successful case reports (in Japanese with English abstract). Nippon Kokyuukigeka Gakkaizassi 2001;15:705-12. (Jpn J Chest Surg).
  6. Iverson LI, Young JN, Ecker RR, et al. Closure of bronchopleural fistulas by an omental pedicle flap. Am J Surg 1986;152:40-2. [Crossref] [PubMed]
  7. Seify H, Mansour K, Miller J, et al. Single-stage muscle flap reconstruction of the postpneumonectomy empyema space: the Emory experience. Plast Reconstr Surg 2007;120:1886-91. [Crossref] [PubMed]
  8. Paletta CE, Huang DB. Intrathoracic application of the reverse latissimus dorsi muscle flap. Ann Plast Surg 1999;43:227-31. [Crossref] [PubMed]
  9. Takeuchi M. Therapy of the empyema (in Japanese). PEPERS 2011;53:39-46. Available online:
  10. Kondo D, Kita Y. A successful case report of conservative treatment of MRSA empyema after right pneumonectomy (in Japanese with English abstract). Kyobu Geka 1995;48:592-4. (Jpn J Thorac Surg). [PubMed]
Cite this article as: Sakakura N, Mizuno T, Kuroda H, Sakao Y, Uchida T. Surgical treatment of empyema after pulmonary resection using pedicle skeletal muscle plombage, thoracoplasty, and continuous cavity ablution procedures: a report on three cases. J Thorac Dis 2016;8(6):1333-1339. doi: 10.21037/jtd.2016.04.04
