Tracheo-innominate artery fistula caused by isolated innominate artery pseudo-aneurysm rupture

Introduction

Tracheo-innominate fistula (TIF) is a very rare but fatal complication of tracheostomy, with an incidence of 0.1–1.0% (1). Isolated innominate artery aneurysm is also rare but its treatment is essential due to the risk of aneurysmal rupture and a subsequent thromboembolic event. Isolated innominate artery aneurysm may cause the extrinsic compression and erosion of the trachea and, very rarely, the development of TIF (2). Here we present a case of TIF caused by the rupture of an innominate artery aneurysm.

Case presentation

A 45-year-old female was admitted to our hospital due to dyspnoea and underwent ventilator care for necrotising pneumonia on the day of admission. However, the pneumonia progressed to acute respiratory distress syndrome, for which she underwent veno-venous extra-corporeal membrane oxygenation on day 1 until day 8 post-admission. On day 12, both chest computed tomography (CT) and a tracheostomy were performed. The chest CT findings were consistent with necrotising pneumonia with para-pneumonic effusion; the innominate artery was normal (Figure 1A). The patient was weaned from the ventilator on day 3 after the tracheostomy and transferred to the general ward on day 31 after admission. A second chest CT performed 13 days after the tracheostomy revealed a slightly improved lung lesion and no abnormal findings around the innominate artery (Figure 1B). At the same time, aspergillosis infection was histologically confirmed in the lung and airway. A third, follow-up CT performed on day 42 post-admission showed extrinsic compression of the trachea, which had not been seen on the chest CT because it was performed without the use of contrast material (Figure 1C).

Figure 1 Chest computed tomography (CT) shows a normal innominate artery before tracheostomy (A) and on day 13 after tracheostomy (B), and extrinsic compression of the trachea (white arrow) on day 42 after admission (C).

On day 14 post-tracheostomy, sudden massive bleeding occurred at the tracheotomy site accompanied by oxygen desaturation, bradycardia and hypotension. Oral endotracheal intubation was immediately performed, followed by local compression with a Foley catheter balloon through the tracheostomy site. After the immediate bleeding had been controlled, emergency angiography revealed a ruptured pseudo-aneurysm of the innominate artery (Figure 2A). The ruptured vessel wall was sealed and reconstructed by inserting overlapping Wallgraft stents (Carotid Wallstent™ and Monorail™; Boston Scientific Corporation, Natick, MA, USA) in the innominate artery. On the second angiography there was no leakage of contrast medium (Figure 2B). After removal of the Foley catheter balloon, there was no further bleeding at the tracheostomy site and the patient was sent to the intensive care unit with stable vital signs. There, she underwent a bronchoscopy, which showed the pseudo-aneurysm, the formation of a hematoma around the aneurysm and no active bleeding focus (Figure 3A). A chest CT taken to assess the results of the intervention continued to show a 2.2-cm pseudo-aneurysm and a stent endoleak was suspected (Figure 3B). Urgent surgery for aneurysmal resection was recommended but the patient’s family refused. Massive bleeding recurred 1 day after stenting and, despite all attempts at resuscitation, the patient died.

Figure 2 Angiography shows TIF and innominate artery stenting. (A) Angiography reveals the formation of a pseudo-aneurysm of the innominate artery; (B) the ruptured aneurysm was sealed by stent graft.

Figure 3 Post-stenting bronchoscopy and CT finding. (A) A post-stenting bronchoscopy shows the pseudo-aneurysm (black arrow) and a hematoma around the aneurysm, but no active bleeding focus; (B) the post-stenting chest CT still shows a 2.2-cm pseudo-aneurysm (white arrow) and the suspected stent endo-leak.

Comments

In general, TIF is defined as massive bleeding into the airway through the fistula, created by inflammatory necrosis between the trachea and the innominate artery subsequent to a compression injury between the tracheostomy tube and innominate artery. Bleeding of the tracheostomy site without fistula, following direct erosion of the innominate artery by the tracheostomy tube, is also included in the broad definition of TIF. Therefore, massive bleeding of the tracheostomy site due to rupture of an innominate artery aneurysm can also be considered as a TIF, albeit a very rare type (1).

In the patient described herein, the first chest CT scan, performed 25 days before aneurysmal rupture, showed a normal innominate artery, with sufficient distance between the tracheostomy site and the primary site of the aneurysm. In addition, the patient had no history of intervention or trauma involving the surrounding innominate artery. Given, the prolonged, severe aspergillosis infection around the tracheostomy site and the trachea, the innominate artery aneurysm might have been caused by vascular infection. There are two possible causes of aneurysmal rupture: tracheostomy-related erosion and spontaneous rupture after aneurysmal dilatation.

Regardless of the clinical courses of a TIF, the principles of treatment are similar. The first step is to resolve lethal bleeding with compression and the second step is to maintain ventilation. After these life-saving measures, definitive treatment is necessary to resolve the problem. In the past, surgery was considered the only treatment, but the mortality rate was >75% (1). Recently, endovascular stenting has been used as the primary treatment, although experience is still limited (3-5). In most of those cases, bleeding control was possible and the overall survival rate following treatment was at least 85%. However, considering that most of the reported cases did not involve a TIF with massive bleeding, endovascular stenting may not be superior to surgical treatment for such cases and should be considered as an alternative to surgery. In particular, an analysis of the reported complications revealed that the rate of endoleak associated with the procedure was 25%, all patients required additional stenting or surgery and 30% died during endoleak-related bleeding control efforts (6,7). Thus, although bleeding was successfully controlled by endovascular stent, delayed rebleeding occurred in >30% of these patients, and 50% of those with rebleeding died during bleeding control procedures (7).

Our patient suffered an endoleak after insertion of the stent graft and she died due to rebleeding. Based on a review of the reported literature and this case, we propose that, while stent graft insertion for patients with massive bleeding TIF enables rapid control of bleeding and stabilisation of vital signs, evidence that this approach is the optimal treatment for TIF is lacking. Thus, for now, endovascular stenting should be used as a bridge to successful surgical treatment.

Acknowledgements

This work was supported by a 2-Year Research Grant of Pusan National University.

Footnote

Conflicts of Interest: The authors have no conflicts of interest to declare.

Informed Consent: Written informed consent was obtained from the patient’s family for publication.
